Changing the type of display can produce various forms of graphic output. Powerful Post-Processor The post-processor can automatically create load combinations in accordance with specified design standards. The program’s efficient analysis algorithms yield exceptional versatility and accurate results appropriate for practical design applications.
A large collection of finite elements has been implemented for applications in civil and building structures. Complete Analysis Options midas Gen provides linear and nonlinear structural analysis capabilities. Data Transfer with Tekla Structure, Revit Structures is possible. Midas Gen supports conventional model generation using nodes and elements as well as other means of generating models via data conversion.
Structures of regular patterns such as Truss, Arch and Frame can be readily created by Structure Wizard and inserted into the desired location on the global model. Intuitive Modeling midas Gen enables us to readily create nodes and elements as if we were drawing drawings using the majority of functions used in CAD programs. They offer excellent facilities and productivity for the modeling and analysis of complex, large-scale structures. User-friendly GUI The user-oriented input/output functions are based on sophisticated and intuitive User Interface and up-to-date Computer Graphics techniques.
